Montage Settings Are Here to Simplify Your Workflow

Montage Settings Are Here to Simplify Your Workflow

We’re thrilled to introduce a new enhancement to the Scoring Interface: Montage Settings. This update brings more flexibility and control to how signals are displayed, helping you tailor your scoring view to fit your workflow.

What’s Changing?

Until now, providers had to choose between two static metric sets— Standard and Complete —each time they opened the scoring interface.

We’re moving away from that model.

Here’s What’s New:

You’ll now have two options for signal review:

  • Open Signals
  • Open Signals + Audio Playback

Regardless of your choice, the same set of available channels will be shown—ensuring a consistent, full-picture view.

Default Montage Configuration

To support this transition, we’re introducing an improved default montage that will be preloaded for everyone.

Channels Displayed by Default:

  • Position
  • Pressure
  • Airflow
  • Snoring (signal graph)
  • THX
  • ABD
  • SpO2
  • Pulse
  • Sleep Stage

Visual Settings:

  • Auto-scale all channels automatically
    (New feature!) Automatically adjusts each signal’s scale for optimal visibility by default.

  • Show signals value on mouse over
    Displays signal values when hovering over the graph by default.

  • Annotations color set
    (New feature!) Switch between light and dark colors for annotations. Dark by default.

  • Arrow scroll size
    Sets the amount of time the view scrolls with each arrow press, defaulting to 2 minutes.

Customize Your Montage

Prefer a different layout? You can personalize your signal view and save it as your default.

Each user can save one custom montage, which will automatically load across all future sessions.

How to Save Your Montage:

  1. Open the Signals page in any scoring session and click the “Montage Settings” button at the top.
  1. Adjust the channel visibility, order, and any other settings as needed.
  2. (Optional) Assign a custom name to your montage.
  3. Click “Save Montage.”

That’s it! Your preferred configuration will be applied by default moving forward.

A Note on Channel Availability

Keep in mind:

Only the channels available in the current study will be shown on the montage.

For example:

  • A Pulse Oximeter study may only display SpO2 and Pulse.
  • A HSAT Level 3 will offer a broader set of signals.

Your saved montage will intelligently adapt based on what’s available in each study
